Purpose and characteristics

This machine is mainly used for the plasticization of plastics, the mixing of plastics, the mixing of fillers, the mixing of blended modified materials, the preparation of masterbatch, and the continuous supply of plasticized plastics to the calender.


1. The roller is made of alloy chilled cast iron and has two structures: hollow and peripherally drilled.
2. There are three methods of distance adjustment: manual distance adjustment, electric distance adjustment, and hydraulic distance adjustment.
3. Equipped with emergency stop button, chest touch switch, pull rope switch and other safety devices to ensure the safety of the equipment.

Product parameters

Model		SK450	SK550（560）	SK610	SK660	SK710	SK760	SK810
Roll diameter		450	550（560）	610	660	710	760	810
Roll working length		1500	1680	2030	2300	2600	2800	3000
Front roll linear speed		30	38.46	42.65	44.79	45	45	45
Roll friction ratio		1.27:1	1.22:1	1.22:1	1.22:1	1.22:1	1.22:1	1.22:1
Motor power		55KW	75KW	90KW	132KW	160KW	185KW	200KW
Heating type		Heat transfer oil	Heat transfer oil	Heat transfer oil	Heat transfer oil	Heat transfer oil	Heat transfer oil	Heat transfer oil
Overall dimension	Length(L)	5360	5770	6100	7000	7500	7750	9140
	Width(W)	2130	2190	2300	2860	2800	2860	3200
	High(H)	1650	1590	1730	1750	1920	1970	2080
Weight		15	23	35	45	48	52	69
